Withtand voltage 4,000VAC
Installation compatible with NAM series
Push down type terminal block
NBM(1) - 06(2) - 471(3) - □(4)
(1) Model Name
(2) Rated Current
(3) Line to ground capacitor code
Refer to Product Line-up.
* When the line to ground capacitor code is different, the attenuation characteristic is
different.
(4) Options
D:DIN rail installation type
* The dimensions change when the option is set. Refer to External view.
|
型號 |
漏電流 |
コンデンサ容量（公称値） |
額定電壓 |
額定電流 |
|
NBM-06-000 |
5μA / 10μA max |
なし |
AC 1Φ 250V / DC250V |
6A |
|
NBM-06-101 |
12.5μA / 25μA max |
100pF |
AC 1Φ 250V / DC250V |
6A |
|
NBM-06-221 |
25μA / 50μA max |
220pF |
AC 1Φ 250V / DC250V |
6A |
|
NBM-06-331 |
37.5μA / 75μA max |
330pF |
AC 1Φ 250V / DC250V |
6A |
|
NBM-06-471 |
50μA / 100μA max |
470pF |
AC 1Φ 250V / DC250V |
6A |
|
NBM-10-000 |
5μA / 10μA max |
なし |
AC 1Φ 250V / DC250V |
10A |
|
NBM-10-101 |
12.5μA / 25μA max |
100pF |
AC 1Φ 250V / DC250V |
10A |
|
NBM-10-221 |
25μA / 50μA max |
220pF |
AC 1Φ 250V / DC250V |
10A |
|
NBM-10-331 |
37.5μA / 75μA max |
330pF |
AC 1Φ 250V / DC250V |
10A |
|
NBM-10-471 |
50μA / 100μA max |
470pF |
AC 1Φ 250V / DC250V |
10A |
|
NBM-16-000 |
5μA / 10μA max |
なし |
AC 1Φ 250V / DC250V |
16A |
|
NBM-16-101 |
12.5μA / 25μA max |
100pF |
AC 1Φ 250V / DC250V |
16A |
|
NBM-16-221 |
25μA / 50μA max |
220pF |
AC 1Φ 250V / DC250V |
16A |
|
NBM-16-331 |
37.5μA / 75μA max |
330pF |
AC 1Φ 250V / DC250V |
16A |
|
NBM-16-471 |
50μA / 100μA max |
470pF |
AC 1Φ 250V / DC250V |
16A |
|
NBM-20-000 |
5μA / 10μA max |
なし |
AC 1Φ 250V / DC250V |
20A |
|
NBM-20-101 |
12.5μA / 25μA max |
100pF |
AC 1Φ 250V / DC250V |
20A |
|
NBM-20-221 |
25μA / 50μA max |
220pF |
AC 1Φ 250V / DC250V |
20A |
|
NBM-20-331 |
37.5μA / 75μA max |
330pF |
AC 1Φ 250V / DC250V |
20A |
|
NBM-20-471 |
50μA / 100μA max |
470pF |
AC 1Φ 250V / DC250V |
20A |
|
NBM-30-000 |
5μA / 10μA max |
なし |
AC 1Φ 250V / DC250V |
30A |
|
NBM-30-101 |
12.5μA / 25μA max |
100pF |
AC 1Φ 250V / DC250V |
30A |
|
NBM-30-221 |
25μA / 50μA max |
220pF |
AC 1Φ 250V / DC250V |
30A |
|
NBM-30-331 |
37.5μA / 75μA max |
330pF |
AC 1Φ 250V / DC250V |
30A |
|
NBM-30-471 |
50μA / 100μA max |
470pF |
AC 1Φ 250V / DC250V |
30A |
