• High power & peak power
• Small and compact PCB construction
• Built-in inrush current, overcurrent and overvoltage protection
circuits
• Harmonic attenuator (Complies with IEC61000-3-2 class A)
• Universal input (AC85 - 264V)
• Power factor correction
LF(1) P(2) 150(3) F(4) - □(5) - □(6)
(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Optional
C: with Coating
G: Low leakage current
J1: VH (J.S.T.) conneclor type
R: with Remote ON/OFF
R2: with Remote ON/OFF
S: with Chassis
SN: with Chassis & cover
Please refer to Instruction manual 6.
|
型號 |
輸出電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
LFP100F-24-Y |
1Φ AC85～264V |
103.2W (206.4W) |
24V 4.3A (Peak :8.6A) |
|
LFP100F-36-Y |
1Φ AC85～264V |
100.8W (201.6W) |
36V 2.8A (Peak :5.6A) |
|
LFP100F-48-Y |
1Φ AC85～264V |
100.8W (201.6W) |
48V 2.1A (Peak :4.2A) |
|
LFP150F-24-Y |
1Φ AC85～264V |
151.2W (302.4W) |
24V 6.3A (Peak :12.6A) |
|
LFP150F-36-Y |
1Φ AC85～264V |
151.2W (302.4W) |
36V 4.2A (Peak :8.4A) |
|
LFP150F-48-Y |
1Φ AC85～264V |
153.6W (307.2W) |
48V 3.2A (Peak :6.4A) |
|
LFP240F-24-Y |
1Φ AC85～264V |
240W (Peak: 480W) Convection Cooling |
24V 10A (Peak :20A) Convection Cooling |
|
300W (Peak: 480W) Forced Air Cooling |
24V 12.5A (Peak :20A) Forced Air Cooling |
||
|
LFP240F-30-Y |
1Φ AC85～264V |
240W (Peak: 480W) Convection Cooling |
30V 8A (Peak :16A) Convection Cooling |
|
300W (Peak: 480W) Forced Air Cooling |
30V 10A (Peak :16A) Forced Air Cooling |
||
|
LFP240F-36-Y |
1Φ AC85～264V |
241.2W(Peak: 482.4W)Convection Cooling |
36V 6.7A (Peak :13.4A) Convection Cooling |
|
302.4W(Peak: 482.4W)Forced Air Cooling |
36V 8.4A (Peak :13.4A) Forced Air Cooling |
||
|
LFP240F-48-Y |
1Φ AC85～264V |
240W (Peak: 480W) Convection Cooling |
48V 5A (Peak :10A) Convection Cooling |
|
302.4W (Peak: 480W) Forced Air Cooling |
48V 6.3A (Peak :10A) Forced Air Cooling |
||
|
LFP300F-24-TY |
1Φ AC85～264V |
300W (Peak: 600W) Convection Cooling |
24V 12.5A (Peak :25A) Convection Cooling |
|
360W (Peak: 600W) Forced Air Cooling |
24V 15A (Peak :25A) Forced Air Cooling |
||
|
LFP300F-30-TY |
1Φ AC85～264V |
300W (Peak: 600W) Convection Cooling |
30V 10A (Peak :20A) Convection Cooling |
|
360W (Peak: 600W) Forced Air Cooling |
30V 12A (Peak :20A) Forced Air Cooling |
||
|
LFP300F-36-TY |
1Φ AC85～264V |
302.4W(Peak: 604.8W)Convection Cooling |
36V 8.4A (Peak :16.8A) Convection Cooling |
|
360W (Peak: 604.8W) Forced Air Cooling |
36V 10A (Peak :16.8A) Forced Air Cooling |
||
|
LFP300F-48-TY |
1Φ AC85～264V |
302.4W(Peak: 604.8W)Convection Cooling |
48V 6.3A (Peak :12.6A) Convection Cooling |
|
360W (Peak: 604.8W) Forced Air Cooling |
48V 7.5A (Peak :12.6A) Forced Air Cooling |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
