• High power density (25.7W/inch3)
• High efficiency 93% typ (Input Voltage 230V, Output Voltage 24V)
• For medical electric equipment
(ANSI/AAMI ES60601-1, EN60601-1 3rd, IEC60601-1-2 4th Ed.)
• Suitable for BF application (Output-FG : 1MOPP, Input-Output : 2MOPP)
• 2x4 standard footprint
• With AUX1 (12V 1A), AUX2 (5V 1A) (Option)
• With remote ON/OFF (Option)

GM⁽¹⁾  A⁽²⁾  300⁽³⁾  F⁽⁴⁾  -  □□⁽⁵⁾  -  □⁽⁶⁾

(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Optional
C : with Coating
J1 : VH connector type (J.S.T.)
J3 : Horizontal input connector
       VH connector type (J.S.T.)
R3 : with Sub features (5VAUX, 12VAUX, Remote)

Specification is changed at option, refer to Instruction manual (4 Option and Others)
